8 Channels Fiber Optic PLC Splitter Cable 1x8 Steel Tube Sc Apc Gpon Connector

8 Channels Fiber Optic PLC Splitter Cable 1x8 Steel Tube Sc Apc Gpon Connector

Planar light-wave circuit splitter (PLC Splitter) is a type of optical power management device that is fabricated using silica optical wave-guide technology. It features wide operating wavelength range, good channel-to-channel uniformity, high reliability and small size, and is widely used in FTTX PON to realize optical signal power management.

Technical specifications

1×16 Single Mode PLC Splitter Data Sheet
Operating Wavelength(nm)	1260-1650		Inspected Date		2017/11/21
P/N:	1x16-PLC-0.9-1.0		S/N:		1711116001
Fiber Type	G.657A with 0.9mm lose tube		Fiber Length(m)		≥1.0
Connector Type	SC/APC		Package Dimension(mm)		60×12×4
Storage Temperature	-40~+85℃		Operating Temperature		-40~+85℃
Item	IL(dB)		PDL(dB)		RL(dB)
Wavelength(nm)	1310	1550	1310	1550	1310	1550
Spec.	MAX13.6		MAX 0.25		≥55
Port1	13.11	13.34	0.03	0.03	Pass	Pass
Port2	13.26	13.41	0.03	0.03	Pass	Pass
Port3	13.28	13.15	0.04	0.03	Pass	Pass
Port4	13.39	13.09	0.04	0.02	Pass	Pass
Port5	13.35	13.03	0.03	0.04	Pass	Pass
Port6	13.48	13.40	0.04	0.04	Pass	Pass
Port7	13.33	13.45	0.03	0.02	Pass	Pass
Port8	13.26	13.33	0.04	0.03	Pass	Pass
Port9	13.02	13.33	0.03	0.04	Pass	Pass
Port10	13.46	13.38	0.02	0.03	Pass	Pass
Port11	13.27	13.25	0.02	0.04	Pass	Pass
Port12	13.46	13.15	0.04	0.02	Pass	Pass
Port13	13.24	13.17	0.04	0.03	Pass	Pass
Port14	13.15	13.42	0.03	0.04	Pass	Pass
Port15	13.32	13.44	0.03	0.03	Pass	Pass
Port16	13.02	13.19	0.03	0.03	Pass	Pass
Input	N/A				Pass	Pass
MAX.	13.48	13.45	0.04	0.04	N/A
MIN.	13.02	13.03	0.02	0.02	N/A
Average	13.28	13.28	0.03	0.03	N/A
Uniformity(≤1.0dB)	0.46	0.473	Directivity(dB)		≥55

Key Features

Adopt high strength stainless steel, pass salt spray test
Ferrule core is less than 0.5um
Adopt 100% new raw material, ROHS compliance
Low Insertion loss
Low PDL Compact Design
Good channel-to-channel uniformity
Wide Operating Wavelength: from 1260nm to 1650nm
Wide Operating Temperature: from -40℃ to 85℃

Application

FTTX Systems
PON Networks
CATV Links
Optical Signal Distribution

PLC splitter was widely used in all kinds of optical network solutions , such as Security Monitoring, Optical Communication, Network Construction, CATV and Pon network.
