1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film

Han Xin Communications Limited
Contact Now
    Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers

    Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers
    • Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers
    • Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers
    • Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers
    • Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers
    • Buy cheap 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film from wholesalers

    1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film

    Ask Lasest Price
    Brand Name : Neutral
    Model Number : 30u/9u/6u/3u/1u etc
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 5000pcs per week
    Delivery Time : 2-5 working days
    • Product Details
    • Company Profile

    1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film

    1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film
    Fiber optic polishing film
    Abrasive paper: get rid off the exceeded glue

    Polishing film: 9um, 3um,1um polishing film

    ADS polishing film:final procedure

    Polishing film procedure
    Polishing Step

    Polishing Film
    Polishing Fluid
    Thrust(Std.)
    Polishing Time(Std.)
    Polishing Film Life(Std.)
    Adhesive removal(hand

    polishing)
    Abrasive paper
    None
    Approx 1 to 2kg
    15 Sec
    Dispose of every time
    Grinding(1st polishing)
    9 mic
    Water
    Point 2
    50 Sec
    30 times
    Grinding(2nd polishing)
    3mic
    Water
    Point 2
    50 Sec
    30 times
    Grinding(3rt polishing)
    1mic
    Water
    Point 3
    50 Sec
    30 times
    Grinding(4th polishing)
    ADS(0.05mic)
    Water
    Point 3
    50 Sec
    10 times

    Features

    1. Fiber Optic Polishing Film

    2. Newly developed tapes for the fiber optics

    3. High durability
    4. Advantages of both fixed and dissociated polishing modes with the characteristics of high removal ratio & surface effects

    5. Evenly-sprayed particles on coated surface
    6. Good intensity & flexility, suitable for polishing on different facets
    7. Suitable for polishing with dry, water or oil medium
    8. The fiber polishing film is durable polishing rate compared to existing polishing films and offers economical operations


    Quality 1um 3um 9um 30um Fiber Optic Diamond Polishing Film Round Type Fiber Polish Film for sale
