AB Glue Fiber Optic Materials Optical Fiber Curing Adhesive Epoxy
Resin Original
Two component heat curing epoxy adhesive, also known 353ND fiber
bonding agent for the production of optical component, widely used
in the production of fiber optic connectors.
| Product Name | High Temperature Epoxy EPO-TEK 353ND FIber Optic Epoxy Glue |
| Module Type | 353ND FIber Optic Epoxy Glue |
| Color | amber |
| Consistancy | pourable liquid |
| Viscosity (mixed) | 3000~5000 cps |
| Glass Transition Temp | 12°C |
Features
Reasonable pot-life that allows for low temperature curing to be
realized. It has an amber color change upon cure.
• NASA approved, low outgassing epoxy
• Semiconductor suggested applications: wafer-wafer bonding of CSP;
fabrication of MEMs devices; flip chip underfill.
• Hybrid suggested applications: providing near hermetic seals in
sensor devices, resisting high temperature packaging
• Down-Hole petrochemical fiber optic sensors, resisting >200°C
field conditions
• Fiber optic adhesive designed to meet Telecordia 1221 - suggested
applications:
• Sealing fiber into ferrules, transmitting light in the optical
pathway from 800- 1550 nm range
• Fiber component packaging; adhesive for active alignment of
optics, environmental seal of opto-package, V-groove arrays
• Medical suggested applications:
• Potting Fiber Optic bundles into SST ferrules for light guides
and endoscopes, resisting sterilization cycles of autoclave, ETO,
gamma, H202 plasma.
• Certified to USP Class VI Biocompatiblility Standards for medical
implants; adhesive for catheter devices including stents and guide
wires
• Electronics Assembly suggested applications:
• Used as dielectric layer in the fabrication of capacitors;
laminating PZT ferroelectrics found in ultrasound or ink-jetting
devices
• Impregnating and insulating copper coil windings in motors and
inductor coils. Bonding ferrite cores and magnets.
• Structural grade epoxy found in Hard-Disk drive devices; bonding
of SST metals, kapton, and magnets
