Multifunctional Machine Fiber Optic Equipment 24 Port Epoxy Small
Curing Oven
The multifunctional curing oven using industrial control chip, PID
algorithm control temperature,can set temperature and time , the
digital display temperature, a buzzer to alert. Provide good
human-machine interface, effectively improve the curing speed.
Parameter
- Voltage:AC220V/50Hz,AC110V/60Hz
- Power:130W
- Control range:0~135℃
- Control percise:±1℃
- Timer range:1~99min 99seconds
- Machine Dimension:L 185×W 135×H 95mm
- Net weight:3KG
- Package dimension:L 300×W 245×H 160mm
Timer
When the press on the right of green button, the timer start to
count down,when the time duration reduced to 0, the buzzer will
alert. Alarm,every 2 seconds,and alerting by B sound. When click
again green button, stop alert.If you want to see the temperature,please press the TIME key the
control panel will show the temperature.
View timer
Press the TIME key, the control panel will show the setting timer.
View temperature
Press the TEMP key ,the control panel will show the actual
temperature.
Alert
When time duration reduced to 0, the buzzer alert, every 2 seconds
will alet using B sound.can click any red button cancelled alert.
Setting Time
Hold down theTIME key 2 seconds, can enter the time setting
pattern, the digital will shine, press UP (+) key can increase the
time in operation, press DN (-) key can reduce time in operation.
Click on the TIME key, the exit temperature setting. In the time
setting, if during 10 seconds, don't press key, automatic exit time
setting. Note: after clock started, cann't set time and temperature
Setting temperature
Hold down theTEMP key 2 seconds, can enter the temperature setting
pattern, the digital will shine, press UP (+) key can increase the
temperature in operation, press DN (-) key can reduce temperature
in operation. Click on the TIME key, the exit temperature setting.
In the time setting, if during 10 seconds, don't press key,
automatic exit time setting. Note: after clock started, cann't set
time and temperature
