Table Pneumatic Fiber Optic Equipment Punching Press Connector
Crimping Machine
• Take compressed air as power source, easy to operate.
• There is not noise and environmental pollution generated by
hydraulic system in standby time, power consumption can be saved,
and production costs can be reduced
• Multi-functional purposes is suitable for pressure into the
bearings, punching,riveting, assembly, cutting, etc..
• The shut height can be adjusted according to the size of the
product or the mold.
• Adjustable stroke cylinders, special stroke can be customized,
column height can also be customized.
• Output force is easily adjusted by adjusting air pressure, the
required pressure can be gotten only by adjusting air pressure, it
is simple and convenient.
• Safety design, comfortable operation, human-based consideration
suitable for long-term operation.
• If need to do quick digression during operation, quick exhaust
valve is optional.
Quick Details:
Power source: pneumatic
Weight: 25KG
Machine Height: 700mm
Machine Width: 240mm
Machine Length: 270mm
Machinery features:
• Multi-function could apply to pressing, punching, riveting,
assembling, cut off and so on.
• Adjustable cylinder stroke & customized cylinder stroke as per
clients' request.
• Special design concept aims at operation security, more
convenient, stable and duralbe.
• There is no noisy generated , lower consumption of electrcity and
high efficiency.
• Easy to operate with the machine and make great contribution to
reduce labour intensity.
Application scope:
Widely use in hardware, electronics, appliances, automobiles,
machinery, clocks, instruments and many other industries in the
assembly, printing, cutting, forming, flanging, punching, riveting,
calibrating and stamping processing and fabricaitng.
Distance adjustment
Column on the board after two locking screws to loosen the middle
screw tight until the upper supporting plate can rotate so far.
Then turn the hand wheel can be adjusted up and down stroke.
Pressure adjustment
Gently pull up the upper end of the regulator the clockwise
pressure up, clockwise, by contrast, adjusted to the pressure are
considered satisfactory, and firmly to prevent the pressure change.
The operation is simple and convenient.
Time adjustment
The time relay small round box according to crimp the product tone
corresponding to the time.
Counter
User-friendly points, down one business day, as soon as look at the
counter, you can know the number of production today. Power outages
and the counter still save the data when the power is turned off,
press the middle of the black button on the counter can be reset to
00000.
Automatic drainage
Close push-pull switch on the two pieces together, the the Erlian
cup of water will automatically shoot.
Emergency stop
Work needs to be carefully operating pressure can be connected to
the mold rising rapidly in case of unforeseen circumstances, turn
off the power switch on the control box.
Precautions
Not operate the Machine for a long time, it is recommended that the
two pieces together on the sliding switch, the power switch is
turned off.
